Graphical User Interface
of check boxes, some require to be typed in prompt boxes.
The local Device and Algorithm Parameters Editor window's toolbar includes a few buttons
positioned on the top of the window:
69
Toolbar button
Min.Value
Max.Value
Default
All Default
Description
Clicking on this button opens the editing dialog to modify the
highlighted parameter in the format, most convenient for this
parameter. A double click on the highlighted parameter also opens
the editing dialog.
If the parameter to be modified has an allowed range in which it may
be set, then clicking on the Min.Value button sets the minimal
allowed value to the highlighted parameter.
If the parameter to be modified has an allowed range in which it may
be set, then click on the Max.Value button to set the maximal
allowed value to the highlighted parameter.
Click on this button returns the default value to the highlighted
parameter.
Click on this button returns the default values to all the parameters
displayed in the window.
Depending of the parameter's type ChipProgUSB offers the most convenient format for the parameter
editing:
Method of editing
Drop-down menu
Check Box dialog
Customizing the
parameter
Description
When the parameter value may be picked from a few preset values
the dialog offers a drop-down list with these values. Highlight a new
value in the list and click OK to complete the editing. For example,
some microcontrollers can be programmed to work with different
types of the clock generators, so the menu prompts to select one of
them.
When some options can be set or reset the dialog appears in a form
of several boxes indicating the default or lately set option statuses.
To toggle the option check or uncheck the box. For example, some
microcontrollers allow the locking of a particular part of the memory
by setting several lock bits, so the menu prompts to check the lock
bits represented as a set of check boxes.
When the parameter value may be set freely in an allowed range the
dialog offers a box for entering a new value and a history list
displaying a few recently set values. The dialog prompts with the min
and max values that can be set for each parameter and restricts to
enter the value out of the allowed range. This type of editing is in use
? 2010 Phyton, Inc. Microsystems and Development Tools
